EAM LAB CLASSIC 302 – Power Amplifier
6.500,00€
Description
EAM LAB CLASSIC 302 – Power Amplifier
Uncompromising performance, distortion-free dynamics.
The CLASSIC 302 represents the natural evolution of our previous amplifiers: a concentration of technology and passion designed to redefine the standards of high-fidelity audio reproduction.
Thanks to a new circuit design and the use of next-generation components, we have achieved a superior level of silence, harmonic contrast , and sonic precision. This amplifier is capable of delivering every detail with absolute transparency, even in the most complex musical passages.
Power and refinement
With a power of over 1000W per channel at 2 ohms , the CLASSIC 302 is designed for those who demand the maximum. Not just raw power, but also the ability to capture every minute nuance with an exceptional dynamic range. The sound is amplified faithfully, without distortion , background noise or artificial colorations , fully preserving the original character of the music.
Dual Mono Project: Independence That Makes the Difference
The internal layout is of the dual mono type, with completely independent and decoupled left and right power stages , to ensure maximum separation between the channels and a precise and stable sound image.
Audiophile-quality components
-
Selected high-quality capacitors , chosen for their reliability and sound performance.
-
Two 1000VA toroidal transformers , capable of providing abundant energy reserves even in the most intense musical passages.
Compact, robust, musical
The CLASSIC 302 combines a solid, compact structure with a sensitive, refined musical heart. It’s the ideal choice for high-end systems, recording studios, or anyone looking for the ultimate amplifier, capable of thrilling and engaging with every listen.
Interiors designed for absolute performance
The heart of the CLASSIC 302 has been designed with the utmost care to achieve high performance and total reliability even in the most demanding listening conditions.
The interior is clean, tidy, and essential , with clear functional separation between the various stages. The two enormous toroidal transformers , the true muscles of the amplifier, are mechanically isolated by a solid steel cover that drastically reduces any possible electromagnetic interference with the delicate amplification circuits. This isolation helps keep background noise to a minimum, ensuring extremely quiet and defined sound reproduction .
Always ready energy, limitless dynamics
The filter bank exceeds 80,000 µF , supported by two robust rectifier bridges and the aforementioned large-capacity transformers. This power supply system is capable of providing a continuous and stable flow of energy, ensuring immediate and powerful delivery in every musical passage, even on difficult speakers or under critical load conditions. The dynamic reserve seems inexhaustible , maintaining the sense of realism and involvement intact even at high sound pressure levels .
Extreme reliability, built to last
Completing the power section, 16 high-current transistors per channel ensure impeccable management even in the most extreme environments. This architecture allows the amplifier to operate in complete control, with thermal and electrical reserves that ensure absolute reliability over time, regardless of the type of load or use.
Technical Specifications
Dual mono power amplifier
• RMS power per channel, both channels driven @1Khz
330W @ 8 ohms
600 W @ 4 ohms
1000 W @ 2 ohms
• EIA power per channel, both channels driven / 20hz- 20Khz.
520W @ 8 ohms
900 W @ 4 ohms
1400 W @ 2 ohms
• THD + N – A-weighted – 0.003% at full power into 8 ohms
• input sensitivity
2.4 Vrms for full power @ 8 ohms
• exits
1 pair of 6mm Binding posts
• Input impedance:
47 Kohm via XLR, 22 Kohm via RCA
• Slew/rate
35 V/uS
• Frequency response
From 20 Hz to 80 Khz +/- 2 db
• Channel separation > 80 dB
• A-weighted SNR >110db
• Dimensions 43x 42 x 21 cm. (D x W x H)
• Weight 38 kg
download pdf
USER MANUAL
Technical Specifications
Dual mono power amplifier
• RMS power per channel, both channels driven @1Khz
330W @ 8 ohms
600 W @ 4 ohms
1000 W @ 2 ohms
• EIA power per channel, both channels driven / 20hz- 20Khz.
520W @ 8 ohms
900 W @ 4 ohms
1400 W @ 2 ohms
• THD + N – A-weighted – 0.003% at full power into 8 ohms
• input sensitivity
2.4 Vrms for full power @ 8 ohms
• exits
1 pair of 6mm Binding posts
• Input impedance:
47 Kohm via XLR, 22 Kohm via RCA
• Slew/rate
35 V/uS
• Frequency response
From 20 Hz to 80 Khz +/- 2 db
• Channel separation > 80 dB
• A-weighted SNR >110db
• Dimensions 43x 42 x 21 cm. (D x W x H)
• Weight 38 kg
