ISKRA 1 Blue Daphne MM/MC Phono Stage.

ISKRA 1 Blue Daphne MM/MC Phono Stage.

Phono preamplifier for Moving Magnet and Moving Coil.

Eight different gain settings, compatible with all common MM and MC cartridges.

Audiokultura Iskra1 is a phono stage with a passive RIAA filter placed between
two ultrafast, laser-trimmed amplifiers. Each amplifier has an independently
adjustable gain.
The first amplifier before the RIAA filter, named GainStage1,
has two gain levels: 20dB and 40dB

For MM and MC High Out cartridges GAINSTAGE1 must be 1-ON 2-OFF

For MC Low Out cartridges GAINSTAGE1 must be 1-OFF 2-ON

The second amplifier, located behind the RIAA filter, called GainStage2, has the
ability to work with four levels of gain: 15dB, 20dB, 25dB and 30dB

Selectable input resistance for MM:47 Kohm and for MC:100 ohm,300 ohm,500 ohm,1kohm

Selectable input capacitance:
A table of possible capacitance settings (not included the cable):
      47pF 100pF 100pF 220pF
value sw5. sw.6  sw.7  sw.8
      OFF  OFF   OFF    OFF
47pF  ON   OFF   OFF    OFF
100pF OFF  ON    OFF    OFF
147pF ON   ON    OFF    OFF
200pF OFF  ON    ON     OFF
220pF OFF  OFF   OFF    ON
247pF ON   ON    ON     OFF
267pF ON   OFF   OFF    ON
320pF ON   OFF   ON     ON
367pF ON   OFF   ON     ON
420pF OFF  ON    ON     ON
467pF ON   ON    ON     ON

Precise passive RIAA equalization network

Dual mono and low noise design -> perfectly channel balance and noise floor

Solid steel housing.

3 year guarantee.

Μάρκα

AUDIOKULTURA
