LYRIC Ti 200 Integrated tube amplifier Parallel single-ended Class A, ultra linear. KT 150

LYRIC Ti 200 Integrated tube amplifier Parallel single-ended Class A, ultra linear.

LYRIC Ti 200 KT 150

A poem about a tube amplifier …

The LYRIC Ti 200 embodies the latest developments in our manufactory: A parallel single-ended Class A amplifier with either 2 x EL34, 2 x KT 88, 2 x KT 120, 2 x KT 150 per channel and an output power of 2 x 40W in operation with KT 120 and KT150.

Developer Stefan Noll built the complex, channel-separated power supply unit with Super Fast rectifier diodes, a filter chain made of capacitors and powerful choke coils. This gives the LYRIC Ti 200 a high level of stability and output power, as well as an excellent signal-to-noise ratio.
The components of the input and driver stage are also of excellent quality. In addition, a highly complex ground and signal routing was chosen, in which opposing currents in the supply voltage and the mixing of the sensitive signal currents are prevented. This “Zero Cross Current Control” developed by Stefan Noll himself can be found exclusively in our new LYRIC amplifiers.
A 47-step attenuator is used as a volume control. The attenuator is characterized by high precision and is constructed with closely selected metal film resistors. This absolute high-end volume control offers a maximum of resolution, fine drawing and spatial depth. Of course, this function can also be remote controlled thanks to a stepper motor.

A few words about tube assembly: The input tube is a low-noise 12AX7, which guarantees high dynamics and a wide frequency response. LYRIC chose a 6V6 in a triode circuit as the driver tube. Compared to the “normal” driver tubes, this power tube is much more powerful and has a very low output impedance. As a result, the LYRIC Ti 200 achieves great stability and has no problems with input capacitances in the subsequent power amplification. Apart from that, the type of tube used is characterized by excellent sound properties. The LYRIC Ti 200 delivers contoured bass, wonderful mids and fine, airy highs.
The output transformers were specially developed for the new Ti 200 integrated tube amplifier. Here, emphasis was placed on extremely low distortion, large bandwidth and, above all, low output impedance, so that even impedance-critical boxes are not a problem. As usual, the negative feedback and thus also the damping factor can be optimally adapted to the speakers using a 6-way switch.

Device type:Integrated amplifierLine:2 x 40 W (KT 150),
2 x 38 W (KT 120),
2 x 16 W (KT 88),
2 x 14 W (EL34 / KT77)Distortion factor:<3%Output impedance: 4 and 8 ohmsSNR /
external voltage
distance:96 dBOperating mode:Parallel Single-Ended Class A (Ultralinear)Frequency response:15 Hz to 35 kHz (-1dB)Entrances:5 x lineOptional:Pre-out and / or tape-outCasing:Black or silver (brushed aluminum)Dimensions W / D / H:440 x 382 x 223 mmWeight:34.5 kgTube assembly:Output stage:Optional: 4 x EL34
or KT88 or KT120 or KT150Entry level2 x 12AX7, 2 x 6V6
